Bitumen Penetration Grade 60/70
Bitumen penetration grade 60/70 is semi-hard penetration grade bitumen using as paving grade bitumen suitable for road construction and repair conjointly for the production of asphalt pavements with below technical specifications. This grade of bitumen is mainly used in the manufacture of hot combine asphalt for bases and wearing courses. Bitumen 60/70 is the most used bitumen grade and basic material for all alternative bituminous products.
Bitumen Penetration Grade 60/70 is mainly used in the manufacture of hot mix asphalt for bases and wearing courses. Penetration Grade Bitumen supplied by NEW RELIANCE is petroleum grade bitumen, manufactured from fractional / vacuum distillation of crude oil. The Bitumen supplied by NEW RELIANCE is produced from vacuum residue (short residue) feedstock.
NEW RELIANCE Penetration Grade bitumens are specified by the penetration and softening point test. The designation is by penetration range only. The penetration grade bitumens have a thermoplastic property which causes the material to soften at high temperatures and to harden at lower temperatures. This unique temperature/ viscosity relationship is important when determining the performance parameters such as the adhesion, rheology, durability and application temperatures of bitumen.
Specification of Bitumen Penetration Grade 60/70
| Bitumen 60/70 | Test method | Unit | Specification |
|---|---|---|---|
| Drop in penetration after heating % | ASTM D5-D6 | % | 20 max |
| Ductility @25 °C | ASTM D113 | cm | 100 min |
| Flashpoint °C | ASTM D92 | °C | 232 min |
| Loss on heating(wt) % | ASTM D6 | wt % | 0.2 max |
| Penetration @ 25°C | ASTM D5 | mm/10 | 60/70 |
| Softening point °C | ASTM D36 | °C | 49/56 |
| Solubility in Trichloroethylene | ASTM D2042 | wt % | 99 min |
| Specific gravity @ 25°C | ASTM D70 | Kg/cm3 | 1.01/1.06 |
| Spot test | A.A.S.H.O.T102 | Negative |
